General Product Information
Parent Code | DVP43605 |
Family | Ellesmere |
Product Class | Ceiling |
Product Subclass | Pendant |
Warranty | 5 Years Residential or 20000 Hours Commercial |
Product Dimensions
Product Length / Diameter | 22.5 inches | 571.5 mm |
Product Width | N/A inches | N/A mm |
Product Depth | N/A inches | N/A mm |
Product Height | 12 inches | 304.8 mm |
Minimum Product Height | 16 inches | 406.4 mm |
Maximum Product Height | 55 inches | mm |
Canopy Length / Diameter | 5.25 inches | 133.35 mm |
Canopy Width | N/A inches | Canopy Width (mm) mm |
Canopy Thickness | 0.75 inches | mm |
Lamping Specs
Orientation of Light Source | Sideways |
Total Wattage | 240 |
Number of Sockets | 6 |
Wattage of Individual Bulb Socket | 40 |
Lamp Confinement | Mostly Open |
Socket Type | Candelabra |
Recommended Bulb | |
Voltage (V) | 120 |
Bulbs Included | No |
LED Information (LED Only)
Total Initial Lumen Output | N/A |
Required Dimmer | N/A |
CRI | N/A |
Color Temperature | N/A |
Pipe / Chain / Cord Information
Pipe / Chain Included | Pipe Kit Available |
Pipe Information | 40 (15 + 12 + 9 + 4) x 0.5 Inches Pipe Kit |
Chain Information | N/A |
Wire / Cord | 10 Ft |
Max Sloped Ceiling Angle | ASY0101 Chain & 2 Loops 180 Degrees |
*Conversion 19° to 45° : ASY0101 + Finish (2 loops + 1 chain): For Additional Cost |
Additional Information
Wall / Ceiling Mountable | No |
Up / Down Mountable | N/A |
Installation Height Adjustable | Yes |
Location Certification | Dry Locations Only |
ADA Compliant | No |
Heavy Duty Mounting Kit Available | No |
Additional Kit Available | No |
