General Product Information
Parent Code | DVP44755 |
Family | Gammahydrae CCT |
Product Class | Wall |
Product Subclass | Vanity |
Warranty |
Product Dimensions
Product Length / Diameter | N/A inches | N/A mm |
Product Width | 14 inches | 355.6 mm |
Product Depth | 3.5 inches | 88.9 mm |
Product Height | 0.75 inches | 19.05 mm |
Minimum Product Height | 0.75 inches | 19.05 mm |
Maximum Product Height | N/A inches | N/A mm |
Canopy Length / Diameter | 4.64 inches | 118 mm |
Canopy Width | 0.78 inches | 175 mm |
Canopy Thickness | 6.88 inches | mm |
Lamping Specs
Orientation of Light Source | Sideways |
Total Wattage | 45 |
Number of Sockets | N/A |
Wattage of Individual Bulb Socket | 45 |
Lamp Confinement | Semi Enclosed |
Socket Type | LED (Non-Replaceable) |
Recommended Bulb | N/A |
Voltage (V) | 120 |
Bulbs Included |
LED Information (LED Only)
Total Initial Lumen Output | 1200 |
Required Dimmer | N/A |
CRI | 90+ |
Color Temperature | 3000/4000/5000K |
Pipe / Chain / Cord Information
Pipe / Chain Included | Not Included |
Pipe Information | N/A |
Chain Information | |
Wire / Cord | 8 inches |
Max Sloped Ceiling Angle | |
*Conversion 19° to 45° : ASY0101 + Finish (2 loops + 1 chain): For Additional Cost |
Additional Information
Wall / Ceiling Mountable | Yes |
Up / Down Mountable | No |
Installation Height Adjustable | No |
Location Certification | Dry Location Only |
ADA Compliant | No |
Heavy Duty Mounting Kit Available | |
Additional Kit Available |
