Mount Pearl 20″ Mini-Pendant
Product Description
Mount Pearl 20 Inch Mini-Pendant
Last inventory update: October 7, 2024 8:07 pm
Resources
General Product Information
Product Dimensions
Lamping Specifications
LED Information (LED Only)
Pipe / Chain / Cord Information
Additional Information
General Product Information
| Parent Code | DVP40005 |
| Family | Mount Pearl |
| Product Class | Ceiling |
| Product Subclass | Mini-Pendant |
| Room Category | Ceiling |
Product Dimensions
| Product Length / Diameter | 7.75 inches | 196.85 mm |
| Product Width | N/A inches | N/A mm |
| Product Depth | N/A inches | N/A mm |
| Product Height | 20 inches | 508 mm |
| Minimum Product Height | 21.5 inches | 546 mm |
| Maximum Product Height | 141.50 inches | 3594.1 mm |
| Canopy Length / Diameter | 4.75 inches | 120.65 mm |
| Canopy Width | N/A inches | N/A mm |
| Canopy Thickness | 1 inches | 25.40 mm |
Lamping Specifications
| Orientation of Light Source | Down |
| Number of Sockets | 1 |
| Total Wattage (W) | 40 |
| Wattage of Individual Bulb Socket (W) | 40 |
| Voltage (V) | 120 |
| Lamping Confinement | Semi Enclosed |
| Socket Type | Medium Base |
| Recommended Bulb | DVLA19MC30A |
| Bulbs Included | No |
LED Information (LED Only)
| Initial Lumens Output | |
| Delivered Lumens (2700K) | |
| Delivered Lumens (3000K) | |
| Delivered Lumens (3500K) | |
| Delivered Lumens (4000K) | |
| Delivered Lumens (5000K) | |
| Required Dimmer | N/A |
| CRI | N/A |
| Color Temperature | N/A |
Pipe / Chain / Cord Information
| Pipe / Chain Included | Not Included |
| Pipe Information | N/A |
| Chain Information | N/A |
| Wire / Cord Information | 10 Ft |
| Max Sloped Ceiling Angle | Cord Grip 45 Degrees |
| *Conversion 19° to 45° : ASY0101 + Finish (2 Loops + 1 Chain): For Additional Cost | |
Additional Information
| Wall / Ceiling Mountable | No |
| Up / Down Mountable | Yes |
| Installation Height Adjustable | Yes |
| Location Certification | Dry Location Certified |
| ADA Compliant | No |
| Heavy Duty Mounting Kit Available | |
| Additional Kit Available | No |
