Dorset 4 Light Vanity
Product Description
Last inventory update: May 6, 2024 6:08 pm
Resources
General Product Information
Product Dimensions
Lamping Specifications
LED Information (LED Only)
Pipe / Chain / Cord Information
Additional Information
General Product Information
| Parent Code | DVP37244 |
| Family | Dorset |
| Product Class | Wall |
| Product Subclass | Vanity |
| Room Category | Bathroom |
| Warranty | 5 Years Residential |
Product Dimensions
| Product Length / Diameter | N/A inches | N/A mm |
| Product Width | 36 inches | 913.76 mm |
| Product Depth | 8 inches | 200.88 mm |
| Product Height | 9.5 inches | 240.5 mm |
| Minimum Product Height | 9.5 inches | N/A mm |
| Maximum Product Height | N/A inches | N/A mm |
| Canopy Length / Diameter | 5 inches | 130 mm |
| Canopy Width | N/A inches | N/A mm |
| Canopy Thickness | 0.75 inches | 20 mm |
Lamping Specifications
| Orientation of Light Source | Down |
| Number of Sockets | 4 |
| Total Wattage | 4 X 40 |
| Wattage of Individual Bulb Socket | 40 |
| Voltage (V) | 120 |
| Lamping Confinement | Semi Enclosed |
| Socket Type | Medium Base (E26) |
| Recommended Bulb | E26 A19 Frosted |
| Bulbs Included | No |
LED Information (LED Only)
| Initial Lumens Output | N/A |
| Delivered Lumens (2700K) | N/A |
| Delivered Lumens (3000K) | N/A |
| Delivered Lumens (3500K) | N/A |
| Delivered Lumens (4000K) | N/A |
| Delivered Lumens (5000K) | N/A |
| Required Dimmer | N/A |
| CRI | N/A |
| Color Temperature | N/A |
Pipe / Chain / Cord Information
| Pipe / Chain Included | No |
| Pipe Information | |
| Chain Information | N/A |
| Wire / Cord Information | N/A |
| Max Sloped Ceiling Angle | N/A |
| *Conversion 19° to 45° : ASY0101 + Finish (2 Loops + 1 Chain): For Additional Cost | |
Additional Information
| Wall / Ceiling Mountable | No |
| Up / Down Mountable | No |
| Installation Height Adjustable | N/A |
| Location Certification | Dry Locations Only |
| ADA Compliant | No |
| Heavy Duty Mounting Kit Available | |
| Additional Kit Available | N/A |
