| Watts | 5.6W |
| Voltage | 120V |
| Delivered Lumens (2200K) | N/A |
| Delivered Lumens (2700K) | 580 |
| Delivered Lumens (3000K) | N/A |
| Delivered Lumens (4000K) | N/A |
| Delivered Lumens (5000K) | N/A |
| Bulb Shape | G9 |
| Base Type | G9 |
| Glass Finish | Clear |
| Light Source | LED |
| CRI | 80+ |
| Beam Angle | 360° |
| JA8 Certified | No |
| Enclosed Rated | Yes |
| Operating Temperature | 20°C to 45°C |
| Case Quantity | 144 |
| Life Cycle @ 3 hrs/day | 18 years |
| Energy Cost @ 10.65¢/kWh | $0.45/year |
| Product Height | 2 inches |
| Product Diameter | 0.625 inches |
| Minimum Product Height | 2 inches |
| Maximum Product Diameter | 0.625 inches |
| Product Class | Bulbs |
| Product Subclass | G9 |
| Watts | 5.6 |
| Delivered Lumens (2200K) | N/A |
| Delivered Lumens (2700K) | 580 |
| Delivered Lumens (3000K) | N/A |
| Delivered Lumens (4000K) | N/A |
| Delivered Lumens (5000K) | N/A |
| Bulb Shape | G9 |
| Base Type | G9 |
| Glass Finish | Clear |
| CRI | 80+ |
| Beam Angle | 360° |
| JA8 Certified | No |
| Enclosed Rated | Yes |
| Operating Temperature | 20°C to 45°C |
| Case Quantity | 144 |
| Life Cycle @ 3 hrs/day | 18 years |
| Energy Cost @ 10.65¢/kWh | $0.45/year |
| Warranty | 3 Years |
| Product Height | 2 inches |
| Product Diameter | 0.625 inches |
| Minimum Product Height | 2 inches |
| Maximum Product Diameter | 0.625 inches |
| Stock Code | DVG9BC27A |
| Product Class | Bulbs |
| Product Subclass | G9 |
✓ Smooth and consistent dimming.
☓ Not recommended.
● Inconsistent simming transition.
^ Potential strobing at this level.
MIN Loses dimmability below this level.
MAX Maximum lumens output.
| 2 BULBS | 5 BULBS | 30 BULBS | |||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 20 | 40 | 60 | 80 | MAX | MIN | 20 | 40 | 60 | 80 | MAX | MIN | 20 | 40 | 60 | 80 | MAX | ||||||
| Legrand Adorne Softap ADTP703U | MIN | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ||||||
| Lustron Maestro MACL-153MH | ^ | MIN | ✓ | ✓ | ✓ | ^ | MIN | ✓ | ✓ | ✓ | MIN | ✓ | ✓ | ✓ | ✓ | ||||||||
