Javelin 6 Light Linear
Product Description
Javelin 6 Light Linear
Last inventory update: February 16, 2026 9:44 pm
Planner Code: –
Resources
Javelin 6 Light Linear
Product Description
Javelin 6 Light Linear
Last inventory update: February 16, 2026 9:44 pm
Last inventory update: February 16, 2026 9:44 pm
Planner Code: –
Resources
General Product Information
Product Dimensions
Lamping Specifications
LED Information (LED Only)
Pipe / Chain / Cord Information
Additional Information
General Product Information
| Parent Code | DVP33202 |
| Family | Javelin |
| Product Class | Ceiling |
| Product Subclass | Linear |
| Room Category | Kitchen & Dining |
Product Dimensions
| Product Length / Diameter | 43 inches | 1086 mm |
| Product Width | 12.75 inches | 318 mm |
| Product Depth | N/A inches | N/A mm |
| Product Height | 5.75 inches | 141 mm |
| Minimum Product Height | 11.75 inches | 293 mm |
| Maximum Product Height | 51.5 inches | 1308 mm |
| Canopy Length / Diameter | 4.75 inches | 120 mm |
| Canopy Width | N/A inches | N/A mm |
| Canopy Thickness | 1 inches | 24 mm |
Lamping Specifications
| Orientation of Light Source | Sideways |
| Number of Sockets | 6 |
| Total Wattage (W) | 6 X 25 |
| Wattage of Individual Bulb Socket (W) | 25 |
| Voltage (V) | 120 |
| Lamping Confinement | Fully Enclosed |
| Socket Type | Candelabra Base (E12) |
| Recommended Bulb | E12 T6 Clear |
| Bulbs Included | No |
LED Information (LED Only)
| Initial Lumens Output | N/A |
| Delivered Lumens (2700K) | N/A |
| Delivered Lumens (3000K) | N/A |
| Delivered Lumens (3500K) | N/A |
| Delivered Lumens (4000K) | N/A |
| Delivered Lumens (5000K) | N/A |
| Required Dimmer | N/A |
| CRI | N/A |
| Color Temperature | N/A |
Pipe / Chain / Cord Information
| Pipe / Chain Included | Yes, Pipe |
| Pipe Information | 40 |
| Chain Information | N/A |
| Wire / Cord Information | 120 in |
| Max Sloped Ceiling Angle | 90° (Chain Link) |
| *Conversion 19° to 45° : ASY0101 + Finish (2 Loops + 1 Chain): For Additional Cost | |
Additional Information
| Wall / Ceiling Mountable | No |
| Up / Down Mountable | Down Only |
| Installation Height Adjustable | Yes |
| Location Certification | Dry Locations Only |
| ADA Compliant | N/A |
| Heavy Duty Mounting Kit Available | No |
| Additional Kit Available | N/A |
