Portage 15.75″ Flush Mount
Product Description
Portage 15.75″ Flush Mount
Last inventory update: June 8, 2026 3:30 pm
Planner Code: –
Resources
Portage 15.75″ Flush Mount
Product Description
Portage 15.75″ Flush Mount
Last inventory update: June 8, 2026 3:30 pm
Last inventory update: June 8, 2026 3:30 pm
Planner Code: –
Resources
| Parent SKU | DVP24338 |
| Family | Portage |
| Product Class | Ceiling |
| Product Subclass | Flush Mount |
| Room Category | Living Spaces |
| Product Length / Diameter | 15.75 in | 400 mm |
| Product Width | N/A in | N/A mm |
| Product Depth | N/A in | N/A mm |
| Product Height | 5.24 in | 133 mm |
| Minimum Product Height | 5.24 in | 133 mm |
| Maximum Product Height | 5.24 in | 133 mm |
| Canopy Length / Diameter | 10.39 in | 264 mm |
| Canopy Width | N/A in | N/A mm |
| Canopy Thickness | 0.83 in | 21 mm |
| Orientation of Light Source | Down |
| Number of Sockets | 1 |
| Total Wattage (W) | 1 X 30W |
| Wattage of Individual Bulb Socket (W) | 30W |
| Voltage (V) | 120 |
| Lamping Confinement | Fully Enclosed |
| Socket Type | DC LED |
| Recommended Bulb | N/A |
| Bulbs Included | Yes |
| Color Temperature | 80+ |
| Initial Lumens Output | 3000 |
| Delivered Lumens (2700K) | 2365 |
| Delivered Lumens (3000K) | 2560 |
| Delivered Lumens (3500K) | 2795 |
| Delivered Lumens (4000K) | 2891 |
| Delivered Lumens (5000K) | 2763 |
| Required Dimmer | LED+/Universal |
| CRI | 80+ |
| Pipe / Chain Included | N/A |
| Pipe Information | N/A |
| Chain Information | N/A |
| Wire / Cord Information | 8" |
| Max Sloped Ceiling Angle | N/A |
| Wall / Ceiling Mountable | Yes |
| Fixture Orientation | Down Only |
| Installation Height Adjustable | N/A |
| Location Certification | Dry Locations Only |
| ADA Compliant | N/A |
| Heavy Duty Mounting Kit Available | N/A |
| Additional Kit Available | No |
General Product Information
Product Dimensions
Lamping Specifications
LED Information (LED Only)
Pipe / Chain / Cord Information
Additional Information
General Product Information
| Parent Code | DVP37112 |
| Family | Carisbrooke |
| Product Class | Ceiling |
| Product Subclass | Semi-Flush Mount |
| Room Category | Hallways |
Product Dimensions
| Product Length / Diameter | 21 inches | 528 mm |
| Product Width | 21 inches | 528 mm |
| Product Depth | N/A inches | N/A mm |
| Product Height | 16.5 inches | 414 mm |
| Minimum Product Height | 16.5 inches | 414 mm |
| Maximum Product Height | 16.5 inches | 414 mm |
| Canopy Length / Diameter | 4.75 inches | 120 mm |
| Canopy Width | 4.75 inches | 120 mm |
| Canopy Thickness | 1 inches | 20 mm |
Lamping Specifications
| Orientation of Light Source | Up |
| Number of Sockets | 8 |
| Total Wattage (W) | 8 X 40 |
| Wattage of Individual Bulb Socket (W) | 40 |
| Voltage (V) | 120 |
| Lamping Confinement | Fully Open |
| Socket Type | Candelabra Base (E12) |
| Recommended Bulb | E12 C35 Clear |
| Bulbs Included | No |
LED Information (LED Only)
| Initial Lumens Output | N/A |
| Delivered Lumens (2700K) | N/A |
| Delivered Lumens (3000K) | N/A |
| Delivered Lumens (3500K) | N/A |
| Delivered Lumens (4000K) | N/A |
| Delivered Lumens (5000K) | N/A |
| Required Dimmer | N/A |
| CRI | N/A |
| Color Temperature | N/A |
Pipe / Chain / Cord Information
| Pipe / Chain Included | N/A |
| Pipe Information | N/A |
| Chain Information | N/A |
| Wire / Cord Information | 8 in |
| Max Sloped Ceiling Angle | N/A |
| *Conversion 19° to 45° : ASY0101 + Finish (2 Loops + 1 Chain): For Additional Cost | |
Additional Information
| Wall / Ceiling Mountable | No |
| Fixture Orientation | Down Only |
| Installation Height Adjustable | No |
| Location Certification | Dry Locations Only |
| ADA Compliant | N/A |
| Heavy Duty Mounting Kit Available | No |
| Additional Kit Available | N/A |
